How to use the Grid Model

The aim is to balance electricity generation and storage to meet demand at lowest cost

You will discover which renewables and storage will be needed to replace gas-fired electricity in the UK, and how much it will all cost ... all based upon real-world data.


Introduction: What is the National Grid?

’The Grid’ is the electrical network of generators, transformers and power lines that provides power for the nation. This model uses 10 years of half-hourly records of all wind and solar generation matched against demand - so real-world data - to calculate how much more wind, solar and storage would have been needed to meet demand without coal and gas power.


The Grid’s key mission is to ensure supply ALWAYS meet demand.

Any failure of electricity supply to keep up with demand causes catastrophic ‘blackouts’, such as happened in Texas in 2021 (or Spain in 2025).


Your task is avoid a blackout at the lowest possible cost by adjusting the levels of wind, solar and different forms of storage ... to meet demand:

  • Step 1 - Scale up wind and solar capacity to try to meet UK demand over that same period.
          Real-world data ensures that effects of changing weather reflect in both renewables output and demand.

  • Step 2 - Add storage (batteries) to stockpile surplus power, to release later when wind and solar output are low
          Storage is the key to matching supply and demand

  • Step 3 - Increase demand to simulate the extra load from electrified heating and road transport.
          Switching to heat pumps and electric vehicles could almost eliminate UK carbon emissions.

  • Step 4 - Optimise storage between batteries, pumped storage hydro, hydrogen, and V2G (vehicle-to-grid)
          This is where the real surprises emerge, revealing why hydrogen may be the only viable long-term storage

  • Step 5 - Zoom date range in or out to see how it plays out over time



Step (1) - Scale up renewables:

What if the UK built more Wind and Solar capacity?

UK electricity data records how much power wind, coal, gas, etc generated every 30 minutes since 2015, recording supply and demand across the ever-changing weather and seasons. That’s 175,000 data points. To model a clean grid, the first step is to eliminate all electricity generated from coal/oil/gas/biomass, then scale up wind and solar data to try to take its place:

Use the sliders below to see how energy supply and weather affect the ability to meet demand:



Your browser will not support this graphic. Try enabling Javascript.
☝

HERE

Power SUPPLY exceeds DEMAND
Step 2 (below) saves this surplus energy


(Graph derived from half-hourly figures from National Grid/Elexon and Sheffield Solar)



TEXT_HERE TEXT_HERE TEXT_HERE

We have ANSWERS for you!

How much with 'Net Zero' really cost? Are UK clean energy plans credible? Could batteries make renewables reliable? What about alternatives? find answers to these and much more with our unique grid model.
Photo: Pumped Storage dam (WikiMedia/ Arpingstone)




The model reveals that the biggest problem to solve for a clean energy grid is likely to be long duration energy storage, that has to store vast amounts of energy, yet only be used once or twice a year.
Photo: Pexels / Tuấn Nguyễn Văn

Step (2) - Add storage

Stockpile surplus electricity using batteries or other storage to use when needed later

The best options to store electricity include batteries, pumped storage hydro and hydrogen. Any stockpiles of surplus energy from windy periods can feed back into the grid when there is not enough wind or solar.



Use the sliders to add battery storage:

Your browser will not support this graphic. Try enabling Javascript.

Your browser will not support this graphic. Try enabling Javascript.












GW or GWh?

What's the difference?

Step (3) - Adjust demand

UK needs to double electricity supply
Just 19% of the UK's energy comes from electricity today. 45% is from petroleum products (mostly in transport) , and 29% from natural gas used for heating. Electrifying heating and road transport, which are both three times more efficient, will double UK electricity demand.
Data from Gov.UK

Transitioning to electric heating and road transport will increase demand on the grid

Electrify Road Transport?

Electrify heating (phase out Natural Gas)?

Adds massive load to grid, mostly during winter. The only way to reduce this is to lower demand through energy efficiency:

Insulation 1 in of homes

Heatpumps 2 in of homes



Your browser will not support this graphic. Try enabling Javascript.


STORAGE CAPACITY - GWh -
STORAGE POWER - GW


The next steps look at different kinds of storage, and testing over a much longer period

Step 4 - Optimise Storage

This model uses three main storage technologies
Batteries - Very expensive, cost is determined by the amount of energy stored, but can be up to 90% efficient
Pumped Storage Hydro - also expensive, costs depend on size of reservoir (amount of energy) and the power of turbines. 85% efficient
Hydrogen - electrolysers to make hydrogen and CCGT (turbines to turn it back into electricity) are both relatively cheap, and the amount of energy stored could be almost limitless. However, at least 60% of the precious electricity is wasted during the processes of converting to hydrogen and back to electricity.


Your browser will not support this graphic. Try enabling Javascript.


WIND
SOLAR
NUCLEAR 1
Elec ROADS?
Elec HEATING?
INSULATION
HEAT PUMPS
STORAGE POWER CAPACITY
BATTERIES £ 0Bn
PUMPED
STORAGE 		£ Bn
HYDROGEN 2 £ Bn
CCGT 3
V2G 4

Stored energy

Stored energy (in Thousand GWh): Hydrogen stores (Graphs 2) Battery, Pumped Storage and V2G stores (Graph 3):

Your browser will not support this graphic. Try enabling Javascript.

Your browser will not support this graphic. Try enabling Javascript.



Step 5 - Select Dates

This simulation can cover a time period up to 1 year

Use the 'black bar' sliders to set start and end dates


👈 ADJUST 👉HERE <=Adjust start/end dates => (sliders)

Your browser will not support this graphic. Try enabling Javascript.

Use the two date-zoom sliders above to adjust start and end dates.

The basic looks at a whole year's data, but there are actually 10 years of data available (from 2015 onwards) detailing over 140,000 data periods soon to be developed.


Start grid model


More options

Why to leave out other technologies that could play a role in an electricity grid powered only by renewables:


Interconnectors

Interconnectors linking the UK to other national grids on the continent currently make up a significant share of the UK's electricity. However, if all those other grids also rely on wind and solar, they may not be available to supply power just when the UK needs it. For that reason, this model excludes contributions from interconnectors.


Demand response (also called load shifting)

Shifting power-hungry devices (car charging, heat pumps, industrial processes) to off-peak hours will undoubtedly play an important role in smoothing out the peaks and troughs in demand for electricity (in a very similar way to batteries), but it doesn't address the bigger problem of long term energy storage.


Tidal power

Studies have proposed that tidal barrages could supply up to 7GW of electricity, reliably, for many decades. Similarly tidal flow schemes promise predictable reliable power akin to baseload. But the numbers are too small to contribute significantly to the UK's power supply.


Small Modular Nuclear Reactors

The promise that small modular reactors will be cheaper than large reactors looks like magical thinking to me. I'm not an expert, but the potential savings from the 'modular' construction approach seem less significant than the economies of scale that a single large reactor can deliver. Take the experience of Nu-Scale Power. Its costs ballooned three-fold, even after the project was scaled down in size before being cancelled at huge costs to Idaho consumers. That SMR suffered exactly the same massive cost over-runs as large projects such as Hinkley Point, Flamanville, Vogtle, etc.


)


Full charge/discharge cycles completed:
